| Color |
Green-Yellow |
| Connecting Capacity Main Circuit |
Screw Clamp / Flexible 1x 0.22 ... 4 mm²Screw Clamp / Rigid 1x 0.2 ... 4 mm² |
| Connection Type |
Screw Clamp |
| Dielectric Test Voltage |
3500 V |
| Function |
Ground |
| Gauge Type |
A4 |
| Insulation Material |
Polyamide |
| Mounting On DIN Rail |
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
| Number Of Levels |
1 |
| Pollution Degree |
3 |
| Rated CrossSection |
4 mm² |
| Rated Shorttime Withstand Current Icw |
for 1 s 480 A |
| Recommended Screw Driver |
4 mm |
| Spacing |
6 mm |
| Tightening Torque |
acc. IEC 60947-1 0.5 N·mManufacturer 0.8 N·m |
| Wire Stripping Length |
9.5 mm |
